AutoMeter GAUGE; FUEL LEVEL; 2 1/16in.; 0OE TO 90OF; ELEC; ULTRA-LITE
Part # 4314SKU AU4314
Universal fit
| Brand | AutoMeter |
|---|---|
| Part type | Fuel Pressure Gauge |
| Analog Or Digital | Analog |
| Bezel Color | Brushed Aluminum |
| Bezel Style | Super Bezel |
| Block Adapter Included | No |
| Bulb and Socket Number | 3220 |
| Bulb Technology | Incandescent |
| Electric Or Mechanical | Electric |
| Face Color | Silver |
| Fuel Line Adapter Included | No |
| Gauge Adapter Included | No |
| Gauge Size | 2.0625 in. |
| Hole Size | 52.4mm |
| Illuminated | Yes |
| Lens | Flat Clear |
| Lighting Color | White Incandescent |
| Lighting Type | Incandescent |
| Liquid Filled | No |
| Mounting Bracket Number | 2230 |
| Number Color | Black |
| Outer Bezel Diameter | 2.250 in. |
| Pointer Color | Fluorescent Red |
| Pressure | 0-100 PSI |
| Size | 2.3125 in. |
| Voltage | 8-18 V |
| UPC / GTIN | 00046074043147 |
| Warranty | 1 Year warranty |
- Incandescent Lighting Illuminates Around Perimeter Of Dial
- 12 And 16V Compatible
- Works w/Most 1965-1997 GM Senders
- Incl. Bulb/Socket Assembly/Red And Green Bulb Covers
- Incl. Mounting Hardware/Instructions
- Air-Core Electric Instruments Provide Quick And Accurate Readings
Description
One of the most necessary gauges in a dashboard, AutoMeter makes it easy by offering 5 different resistance range configuration to match your existing fuel sending unit. Available in 0-90 ohm (GM mid 60's to mid 90's), 0-30 ohm (early GM), 73-10 ohm (pre 90's Ford and Chrysler), 16-158 ohm (later model Fords) and 240-33 ohm (aftermarket senders such as the AutoMeter 3262). Our patented air core meter movement receives extra dampening to help combat the effects fuel slosh in non-baffled tanks.
